Fanless & quiet
Elegant & compact
Enhanced energy independence for PV rooftop owners
Efficient solutions for solar power storage are the key to increased levels of energy autonomy. The EH series delivers high yield for single phase systems and enables high backup output. Featuring a modern design that does not require fans for cooling, the operation is silent and reliable. An on-grid, battery-ready version of the inverter is available. The EH series is compatible with a range of batteries, including the GoodWe Lynx Home F.
UPS level switching < 10ms
Smart home integration
IP65 ingress protection
Highly efficient
Fanless & quiet
Elegant & compact
Optimised Energy Autonomy
High backup output power with overload capability. Wide battery voltage range (85-460V) supports various battery capacities and power.
Wide battery voltage range
Integrated dynamic power export limit and load monitoring
Highest Safety Standards
Metal aluminium houseing with IP65 protects the inverter and makes it possible to install it both inside and outside.
IP65 ingress protection
High quality components
ΕΠΙΣΚΟΠΗΣΗ
Model
GW3600-EH
Battery Voltage Range (V)
85~460
Max. Continuous Charging / Discharging Current(A)
25/25
Max. Input Current per MPPT (A)
12.5
Max. Apparent Power Output to Utility Grid (VA)
3600/3960 (CEI 0-21)
Back-up Nominal Apparent Power (VA)
3600
Model
GW5000-EH
Battery Voltage Range (V)
85~460
Max. Continuous Charging / Discharging Current(A)
25/25
Max. Input Current per MPPT (A)
12.5
Max. Apparent Power Output to Utility Grid (VA)
5000/5500 (CEI 0-21)
Back-up Nominal Apparent Power (VA)
5000
Model
GW6000-EH
Battery Voltage Range (V)
85~460
Max. Continuous Charging / Discharging Current(A)
25/25
Max. Input Current per MPPT (A)
12.5
Max. Apparent Power Output to Utility Grid (VA)
6000/6600 (CEI 0-21)
Back-up Nominal Apparent Power (VA)
6000
